Pitch 7.62mm Barrier Style Terminal Blocks American Standard Black Color

Product Description:

CK Series - "BarrierTerminal Blocks"

Barrier Terminal block is a type of electrical connector used to connect two or more wires together securely in various electrical applications. It typically consists of a plastic or metal housing with metal terminals inside. The terminals have a barrier between them, hence the name, which helps to prevent short circuits and ensure proper electrical isolation between the connected wires.

"Barrier Terminal block" is also known as "American Standard Terminal Blocks". These terminal blocks are designed according to American standards and are commonly used for electrical connections and wiring applications. They adhere to specific electrical standards and regulations established in the United States to ensure safe and reliable electrical connections. American standard terminal blocks may differ from terminal blocks in other countries or regions in terms of appearance, dimensions, materials, and certification standards, making them more prevalent in the American market and some other markets.

Product Overview

Alinta's Barrier Terminal Block Series is mainly used in the field of switch power supplies. It offers secure connections, large contact areas, durable and robust insulation housing, as well as resistance to pressure and vibration. It comes in various spacing options, including 6.35mm, 7.62mm, 8.25mm, 9.525mm, 10.0mm, 11.0mm, and 13.0mm. Typically, it is an integrated product, normally available in black. The product is certified by UL, VDE, CQC, CB, and CE, ensuring compliance with international safety standards.

• Mainly used in the field of switch power supply
• Connect tightly and large contact area
• Durable and robust insulation housing
• Resistance to pressure and vibration
• Pitch: 6.35mm, 7.62mm, 8.25mm, 9.525mm, 10.0mm, 11.0mm, and 13.0mm
• Normal color is black
• UL, VDE, CQC, CB, and CE certified

Market:

Industrial Automation, Power Supply,  Switch Power Supply, Internet of Things, Servo Motor, etc.

CK400-15 Barrier Terminal Block Technical Parameters:

=> Pitch 7.62mm

Product Dimension

CK400-15   P=7.62mm   L=P*pole+1.4mm
CK400-15
CK400-18 P=7.62mm    L=P*(pole/2)+5.7+14mm
CK400-16  Double Row    P=7.62mm    L=P*(pole/2)+5.7mm
CK400-16  P=7.62mm   L=P*pole+1.4mm
CK400-22K  P=7.62mm  L=P*pole+1.4mm
CK430-02 P=8.255   L=P*pole+1.80mm
CK430-03 P=8.255mm     L=P*(pole+2) + 1.80mm
CK430-04 P=8.255mm L=P*(pole+2) + 1.80mm
CK430-05 P=8.255mm L=P*(pole+2) + 1.80mm
CK430-09 P=8.255mm L=P*pole + 1.20mm
CK430-09R P=8.255mm L=P*pole + 1.20mm   with dust cover
CK600-00 P=9.525mm, L=P*pole +2.5mm
CK600-01 P=9.525mm, L=P*pole +2.5mm
CK600-15 P=9.525mm, L=P*pole +1.8mm
CK600-16 P=9.525mm, L=P*(pole+2) +1.8mm
CK600-18X P=9.525mm, L=P*pole+11mm
CK700-01 P=10mm, L=P*pole+2.2mm
More options please contact Alinta Electronics to provie catalog.

How to Order:
