Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles
  • Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles
  • Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles
  • Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles
  • Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles
Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles

Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles

Place of Origin CN
Brand Name Alinta
Certification RoHS,REACH
Model Number QC-AY08AG456-R
Product Details
Termination Type:
SMT, 8-feet
Operation Force:
150gf±100gf
Life Cycle:
10000
Travel:
2mm
Highlight:

8-feet SMT slide switch

,

slide switch 150gf actuation force

,

tact switch 10000 cycles lifespan

Payment & Shipping Terms
Minimum Order Quantity
1000
Price
Negotiable
Packaging Details
Tape & Reel
Delivery Time
5-8 days
Payment Terms
T/T
Supply Ability
25KK per month
Product Description

Product Type: QC-AY08AG456-R

Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 0Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 1


 /Parameter

Current/Voltage RatingDC 12V 200mA
Insulation Resistance ≥100MΩ
Contact Resistance ≤100mΩ
Life Cycle10000
Withstand Voltage500V AC Min
Operating Temperature-20 to 85°C
Operation Force150gf±100gf
Solderability255°C Max Solder Temperature



/Material

ButtonPA46 Black
CoverSUS
ShrapnelBeryllium Bronze, AG plating
TerminalBrass, AG plating
HousingPA6T Black



/DIMENSION/SCHEMATIC


Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 2
Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 3          Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 4

/Market/Application

Audio/TV, Mobile, Healthcare, Home Appliance, Smart Meter, Energy/Industrial Equipments

/Production Overview

Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 5



Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 6



Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 7


CCD Inspection Equipment

Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles 8


--------------------------------------------------------
ALINTA Factory boasts a fully automated production line for sliding switches and advanced inspection equipment, supported by a rigorous management system and professional personnel, ensuring that every product delivered to our customers is safe and reliable.
Welcome to contact us for any product inquiries and welcome to visit our factory in China.
